Immersive clean aesthetics

Our signature narrow bezel frame accentuates your media content.

we pay close attention to design, as the display itself should be just as eye-catching as its content.

we kept things simple with this one.

2500 nits brightness.

All aluminum body.

Available sizes: 32",  43",  55",  65", 70", 75", 82",  84"

Available colors: Rose Gold, Silver, Black


TECH SPECS

Digital signage

PANEL

Resolution : 1920 X 1080(32" 43" 55" 65" 70" 75" 82") / 3840 x 2160 (84")

Brightness(nits) : 2500 (43" 55" 65" 70" 75" 82")  / 2000 (32" 84")

Contrast  Ratio : 1400:1 (32") / 4000:1 (43"  55"  65"  70" 75" 82" 84")

Backlight : vertical led light source

Refresh Rate (ms): 8 (32") / 6 (43" 55" 65" ) / 5 (70" 75" 82" 84")

Viewing angle  : 178° /  178°

Service Life (hours) : 50,000



FUNCTIONAL CHARACTERISTICS

Video Input : USB × 1 , SD × 1 , HDMI x 1

USB, SD Supports Video Formats : support extended .avi , mpg , dat, rm / rmbv , wmv

USB, SD Supports Audio Formats : support extended .mp3 , wma ,m4a /aac

USB, SD supports Image Formats : support extend .jpg / jpeg , bmp , png

Audio Output (w) : 2 x 5

Timing on-off : Free set Multi-period time

Abnormal Voltage Protection : /

Intelligent temperature control system : Intelligent temperature control function can automatically control the working situation of cooling fan according to environment, to ensure that products can work in environment of high temperature.



POWER SUPPLY

Standby Power Consumption (w) : 2

Shutoff Power Consumption (w): 0.5

Intelligent Optical Sensor : With automatic function of light sensing. Self-regulation of screen brightness according to the light intensity of environment.

Outdoor Grade : sunlight readable , no blacking

Max Power Consumption(w) :  125(32") /  215 (43") / 355(55")  / 450(65") / 690(70") / 1150(75") / 1050(82") / 1850(84")



PHYSICAL SPECIFICATIONS

Dimension(w x h x d  mm) : 784 x 478 x 110 (32")  /  1,015 x 608  x 108 (43") / 1,300 x 780 x 120 (55")  / 1,513 x 888 x 120 (65") / 1,930 x 1160 x 85 (84")
