minimalist design

we kept things simple with this one.

2500 NITS brightness.

All aluminum body.

Available sizes: 32",  43",  55",  65", 70", 75", 82",  84"

Available colors: Rose Gold, Silver, Black

TECH SPECS

digital signage

PANEL

Resolution : 1920 X 1080(32" 43" 55" 65" 70" 75" 82") / 3840 x 2160 (84")

Brightness(nits) : 2500 (43" 55" 65" 70" 75" 82")  / 2000 (32" 84")

Contrast  Ratio : 1400:1 (32") / 4000:1 (43"  55"  65"  70" 75" 82" 84")

Backlight : vertical led light source

Refresh Rate (ms): 8 (32") / 6 (43" 55" 65" ) / 5 (70" 75" 82" 84")

Viewing angle  : 178° /  178°

Service Life (hours) : 50,000



FUNCTIONAL CHARACTERISTICS

Video Input : USB × 1 , SD × 1 , HDMI x 1

USB, SD Supports Video Formats : support extended .avi , mpg , dat, rm / rmbv , wmv

USB, SD Supports Audio Formats : support extended .mp3 , wma ,m4a /aac

USB, SD supports Image Formats : support extend .jpg / jpeg , bmp , png

Timing on-off : Free set Multi-period time

Abnormal Voltage Protection : /

Intelligent temperature control system : /

POWER SUPPLY

Standby Power Consumption (w) : 2

Shutoff Power Consumption (w): 0.5

Intelligent Optical Sensor : With automatic function of light sensing. Self-regulation of screen brightness according to the light intensity of environment.

Outdoor Grade : sunlight readable , no blacking

Max Power Consumption(w) : 110(32") /  200 (43") / 340(55")  / 420(65") / 660(70") / 1100(75") / 980(82") / 1200(84")



PHYSICAL SPECIFICATIONS

Full Body Dimension(h x w x d  mm) : 722.4 x 423 x 60 (32")  /  956 x 554  x 92 (43") / 1,235 x 714 x 113 (55") / 1,455 x 840 x 125 (65") / 1,930 x 1,160 x 85 (84")
