35 inch Shelf Edge Display
KW35
35 Inch LCD Screen
Resolution:3840 x 200
Brightness: 500 Nits
Slim Design
Full Metal Shell
Brightness: 500 Nits
BLU: E-LED
Features
Maximize Limited Space with Ultra-Wide Digital Experiences
KEEWIN Bar Display is a professional stretched LCD signage solution designed for environments where conventional displays cannot fit.
With ultra-wide aspect ratios, slim industrial design, and multiple size options, KEEWIN Bar Displays transform narrow spaces into powerful digital communication platforms.
Perfect for retail shelves, transportation systems, smart cabinets, restaurants, elevators, and public information displays.
TECH SPECS
35.0" 500nits Bar Display
KW350TXP02-V02
Display
| Model | DV350FBM-N10 |
| LCD Technology | ADS |
| Screen Size | 35.0 inch |
| Resolution | 3840 × 200 |
| Brightness | 500 nits |
| Backlight | E-LED |
| Contrast Ratio | 1000 : 1 |
| Viewing Angle (H/V) | 178° / 178° |
| Backlight Life | 30,000 Hrs (Min.) |
Internal Player / I/O
| I/O Interfaces | HDMI in ×1 |
Power
| Power Supply | DC 12V |
| Power Consumption | ≤ 24 W |
Environment
| Operating Temperature | 0 °C ~ 50 °C |
| Operating Humidity | 20 % ~ 80 % RH |
Physical
| Body Dimension (W × H × D) | 891.6 × 60.4 × 24.84 mm |
| Set Weight | 2.25 kg |
| Package Dimension (4 pcs) | 960 × 410 × 150 mm |
| Package Weight (4 pcs) | 11 kg |
