43inch Outdoor Digital Advertising Signage

KWO43-66-Lite

  • 43 Inch FHD LCD Screen

  • Optical Bonding + AG / AR coating tempered Glass

  • High Tni 105℃ Panel

  • High Brightness: 2500Nits

  • IP66-Fully Enclosed System

  • IP66 Rating - Maintenance Free

  • Android OS / Windows OS / TV Board

Inquiry to Buy

Accessories:

ceiling hanging | Floor Standing | Electronics Enclosure

Certifications: CE, Rohs, IP66, IK10, ATEX

TECH SPECS

  • Size: 43 inch

    Active Display Area ( H x V mm ): 942.5 × 531

    Aspect Ratio: 16:9

    Resolution: 1920 × 1080

    Brightness: 2500nits

    Backlight Adjustment: Automatic (Ambient Light Sensor)

    BLU: D-LED

    Contrast Ratio: 1200:1

    Viewing Angle(H/V): 178°/178°

    Backlight Life: 50,000 Hrs

  • Dimensions (W x H x D) : 1017.5 × 606 x 107 mm

    Net Weight : 32 kg

    Enclosure Material: Aluminum + Steel

    Finishing : Fine Grain Powder Coating

    Colour: Black (Ral 9005)

    Glass: AR Coating Tempered Glass,Back Painted Pantone Black C

  • AC Input: 100~240VAC±10% , 50 / 60 Hz

    Max Power Consumption: 210 w

  • IP Rating: IP66

    Operating Environment: Fully Outdoor

    Operating Temperature: -30°C~50°C

    Operating Humidity: 5%~98%

  • HDMI Input ( Version 1 ): HDMI ( x 1)

    Android OS ( Version 2): Android 14, 4+32G

    Window OS ( Version 3): Windows OS i5, 8+128G

Product Documents

Product Datasheet
CAD Drawing
