75” Outdoor High Brightness Digital Signage
KWO75-66
75 Inch 4K LCD Screen
Optical Bonding + AG /AR Coating Tempered Glass
High Tni 105℃ Panel
High Brightness: 2500Nits
IP66-Fully Enclosed System
Maintenance Free
Android OS / Windows OS / TV Board
Accessories:
ceiling hanging | Floor Standing | Electronics Enclosure
Certifications: CE,Rohs, IP66,IK10,ATEX
Features
TECH SPECS
75" 2500 nits UHD Outdoor Digital Signage
KWO75-66 M SERIES
LCD Display
| Screen Size | 75 inch |
| Active Display Area (H × V) | 1649.664 × 927.936 mm |
| Resolution | 3840 × 2160 |
| Brightness | 2500 nits |
| Aspect Ratio | 16 : 9 |
| Backlight Adjustment | Automatic (Ambient Light Sensor) |
| Viewing Angle (H/V) | 178° / 178° |
| Backlight Configuration | Direct LED |
| Operation Life | 50,000 Hours |
Environment
| IP Rating | IP66 |
| Operating Environment | Fully Outdoor |
| Operating Temperature | -30°C ~ 50°C |
| Operating Humidity | 5% ~ 98% |
| Operating Altitude | ≤ 2000 m |
Mechanical
| Dimensions (W × H × D) | 1024 × 1745.5 × 107 mm |
| Net Weight | 80 kg |
| Enclosure Material | Aluminum |
| Finishing | Fine Grain Powder Coating |
| Colour | Black (RAL 9005) |
| Glass | AR Coating Tempered Glass, Back Painted Pantone Black C |
Power
| AC Input | 110~220 VAC ±10%, 50 / 60 Hz |
| Power Consumption | 560 W |
Media
| HDMI Input | HDMI ×1 |
| RS232 | RS232 ×1 |
