Touch to Order

Fast food restaurants, train stations and airports are all restaurant sectors where time is a critical factor for customers who would like to finish meal quickly . In order to satisfy faster sales and better user experience, Keewin has designed a custom kiosk. As an effective alternative to POS, Customers can complete the order directly on the kiosk. The kiosk integrates a wide range of devices: 3D Camera, Thermal Printer, Pos Terminal and QR Code Scanner.

Available sizes (inch) : 32, 43, 49, 55

Available colors:  Black, White, Gray


TECH SPECS

PANEL

Panel Size (inch)

LCD Manufacturer

Active Display Area (w x h mm)

Resolution (pixel)

Aspect Ratio

Brightness (nits)

Contrast Ratio

Grey to Grey Response Time (ms)

Viewing Angle (H/V)

Backlight Configuration

Operational Life Cycle (hours)

32

LG / Samsung / AUO / SHARP

698 x 392

1920 x 1080

16:9

450

1300:1

8

178° / 178°

led backlight source

50000



Media & Connectivity

Operating System

CPU

Graphics Card

Memory

Storage

LAN

RS232

USB

Speakers

WIN7 64bits

i3 / i 5

Intel HD Graphics 4400

4 G

128 G SSD

x 1

x 2

x 4

8Ω 5W x 2



Power

Input Voltage

Max Power Consumption (w)

AC 220 / 110 V ± 10%, 50 / 60 HZ

70



Enclosure

IP Rating

Enclosure Material

Enclosure Lifetime

Glass Type

Touch

Unit Dimension (w x h x d mm)

Bezel Width (mm)

Weight (kg)

IP4X

Steel

10 years

Ultra-clear low iron glass

10 Points Simultaneous

520 x 1,230 x 150 ( wall mounted ) / 520 x 1,850 x 150 ( floor standing )

65

90



Environment

Indoor
0℃ ~ +40℃
5% ~ 98%
≤ 2000 m

Operating Environment
Operating Temp.
Operating Humidity
Operating Altitude
